Equipment parameters：
| Description | Specifications |
| Model | ARP-100 AOI 3D |
| Industry Applications | SMT, PCBA, Semiconductor, Industrial |
| Inspection Functions | Missing parts, Offset, Skewed, Polarity, Reverse Parts, Tombstone, Warping, Side Standing, Lifted/Bent Leads, Excess/Insufficient Solder, Poor Welding/Solder, Overturn, Bridging, Wrong Part (OCV Marking), Pin Through Hole (Solderability & Pin Detection), Package Coplanarity, Lifted Lead (Height Measurement), More/Less Tin, Climbing Tin, Pad Pollution, Foreign Material Detection, Polarity Dimple Measurement |
| Inspection Interface Function | 29 Basic Detection Boxes |
| Index Time | Modeling < 10 Min |
| Performance Characteristic | First Pass Yield (FPY) of Single Board＞99% Overkill 30 DPPM High Speed 0.4s/FOV |
| Operating System / Interface | JRS supplied API for Windows 10-based Color Touchscreen Language: English and Chinese (Simplified), other upon request |
| Lighting System | 5 Different Light Source Choices： White Light Low Angle (Tin Type Light) Color Light True Color Drawings 3D Gray Medium |
| Resolution Ratio (um) | 10.62 / 12.14 / 15.15 / 17.08 |
| Image Range / FOV (m㎡) | 43.5 x 32.6 / 49.7 x 37.3 / 62.1 x 46.6 / 70 x 52.5 |
| Scanning Speed (cm²/sec) | 28.36 / 37.1 /57.8 / 73.5 |
| 3D Technologies | 4-way Projection, Fusion Depth Mapping |
| Single Field Speed | 0.45s / FOV |
| Vertical Resolution | < 1um |
| Vertical Alignment Accuracy | < 3um (3 sigma) |
| Camera Vision Accuracy | 10μm, 12μm, 15μm, 6μm |
| Standards | CE/UL |
| Conveyor Width Adjustment | Auto Width Adjustment; Bottom-Up Clamping; In-line SMEMA Single Track Minimum (50x50mm) and Maximum (500x400mm); Dual Track Minimum (50x50mm) and Maximum (300x400mm) |
| Board / Lot Tracebility | Camera-Read Barcodes; External Barcode Reader Configured; OCR Capability with Batch Code Logging |
| Facility Requirements | Operating Voltage: AC 220V Air Pressure Requirements: ≥ 0.5MPA Power：2.5KW |
| Dimensions | Overall Dimension: 1390*1080*1700mm |
| Weight | 1200 KG |
*The above parameters are subject to the actual product
